BCS-P-TIP58FSR8-AI2(2)

Data sheet

Product

BCS-P-TIP58FSR8-AI2(2)

Product line

BCS POINT

NDAA

National Defense Authorization Act

Camera type

Bullet

Resolution

8 Mpx

Sensor

1/2.8'' CMOS

Scanning system

Progressive Scan

Pixels

3840(H)×2160(V)

Lens

fixed

Focal length

2.8 mm

Aperture

F1.6

Focus

fixed

Iris

fixed

Angle of view

H: 97.49° V: 52.31° D: 102.29°

DORI

Detect 86.9m / Observe 34.8m / Recognize 17.4m / Identify 8.7m

Min illumination

0.002Lux(F1.6,AGC) 0Lux(B/W,IR)

S/N ratio

56dB

White balance

(AWB) Auto / manual

WDR

130dB

Backlight compensation

BLC / HLC / WDR(130dB)

Shutter

Auto / manual 1~1/100000s

Gain control

(AGC) Auto / manual

Noise reduction

2D/3D DNR

RoI

Region of Interest

Defog

Digital

Image rotate

Mirror, Flip 0°/90°/180°/270°

Stream support

3

Resolutions

8M(3840×2160) / 5M(3072×1728) / 4M(2560×1440) / 2M(1920×1080) / 720P(1280×720) / D1(720×576) / (640×360) / 2CIF(704×288) / CIF(352×288)

Main stream

3840×2160@30fps 3072×1728@30fps 2560×1440@30fps 1920×1080@30fps

Second stream

1280×720@30fps 720×576@30fps 640×360@30fps 704×288@30fps 352×288@30fps

Third stream

720×576@30fps 640×360@30fps 704×288@30fps 352×288@30fps

Bitrate

128Kbps~16Mbps

Video compression

H.265 / H.265+ / H.264 / MJPEG

Day/night

ICR

Illuminator type

IR LED

IR range

80m

Microphone

Yes

Audio in

1

Audio out

1

Audio compression

G.711A / G.711U

Alarm in

1

Alarm out

1

Storage

NAS(NFS)

Memory card slot

microSD 512GB

Support

Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android)

Motion detect

Yes

Privacy masking

4

Network

RJ-45 10/100Mbps

Compatibility

ONVIF(S/G/T/M)

Protocols

IPv4, IPv6, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, SSL/TLS, SSH

Network security

Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF

Power supply type

12V DC / PoE(802.3af)

Power consumption

max 10.5W

Housing color

Graphite

IP class

IP67

IK10

Yes

Surge protection

4kV

Working environment

-30°C~+60°C max 95% RH

Dimensions

269×96×82mm

Weight

0.86 kg

Ai - Built-in intelligent functions

Built-in intelligent algorithm of image analisis

Ai - Perimeter protection

Crossline, intrusion

Ai - Human/vehicle detection

Recognition of people entering the area and crossing the line reduces false alarms.

Ai - People counting

People counting for intrusion and crossline, counting people in/out

Ai - SMD - Smart Motion Detection

Intelligent Ultra Motion Detection with human/vehicle recognition
